D-Link DCS-8600LH
Full HD Outdoor Wi-Fi Camera
Sorry, this product is no longer available, Please contact us for a replacement.
Overview:
Your Home, Only Smarter
The DCS-8600LH Full HD Outdoor Wi-Fi Camera boasts a wide-angle lens that easily captures your entire outdoor area, from door to curb, in high-quality 1080p. You will know what is happening day or night with built in night vision, motion and sound detection sending notifications to the mydlink™ app. The rotatable head makes discrete installations easy even on ceilings. It has an IP65 rating, which means it can withstand outdoor weather environments such as rain or snow, and on cold and hot days it still can be placed outdoors.
Strength to Brave the Outdoor Elements
The camera and power cords are designed to be capable of withstanding the harshest winter temperatures from -4 °F all the way up to blistering summer heat waves of 113 °F. With an IP65 rating, the camera can withstand torrential rain and blizzards, and the surface of the camera does not have any gaps or crevices that could trap dust and ice. Perfect for keeping an eye on the most exposed outdoor areas of your home like the driveway, the front or back doors, and the garage. This camera is great for homes in heavy tropical, harsh winter, and desert environments.
Peace of Mind with 24/7 Complete Coverage
The DCS-8600LH uses a 135° wide-angle lens and a 1080p HD sensor to give you a clear view of the outside of your home. Round the clock monitoring is enabled by built-in infrared LEDs allowing up to 23 feet of night time viewing. The special magnetic design makes ceiling, wall, and doorway installations a breeze while wireless 802.11n keeps cabling to a minimum.
Anytime, Anywhere Access with mydlink™ Cloud Recording
Enhanced with mydlink™ cloud recording support, the DCS-8600LH makes it easy and convenient for you to look after your family and belongings by checking up on the outdoor areas surrounding your home or office. With a mydlink™ cloud recording subscription, you can have peace of mind with your video recordings sent automatically to a cloud server. Play back recordings from the cloud or download video clips to your mobile device from anywhere, anytime through the Internet. Access real-time live views of your cameras using the mydlink™ mobile app and set automated schedules via your mobile device, no matter where you are.
Features
- Weatherproof housing and cabling
- High quality Full HD sensor provides detailed snapshots and crisp video
- Built-in IR LEDs to capture video in low-light environments or even complete darkness up to 23 ft
- Motion and sound level detection
- Push notification for events and save video clips to microSD card or send to cloud storage
- Wireless N usage allows you to install the camera anywhere with ease without having to worry about network cables
- Uses 2T/2R high efficiency WiFi module to improve wireless performance
- Backwards compatible with 802.11g/b
- View and manage your camera using the mydlink™ app
- Two-way audio
- 135-degree viewing angle
- AES128-encrypted video and audio streaming
Technical Specifications:
| D-Link DCS-8600LH Technical Specifications | ||
|---|---|---|
| Camera | ||
| Hardware Profile | • 1/2.7” Progressive CMOS sensor • 23 ft IR illumination distance • Minimum illumination: B/W (Night Mode), IR LEDs on: 0 lux • Built-in Infrared-Cut Removable (ICR) Filter module • Lens fixed focal length 1/8” • Aperture F2.4 • Angle of view (16:9): Horizontal: 117°, Vertical: 59°, Diagonal: 135° • Built-in microphone • Built-in speaker |
|
| Image Features | • Configurable image size • Configurable sound level detection • Configurable motion detection windows |
|
| Video Compression | • Simultaneous H.264/MJPEG format compression • JPEG for still images |
|
| Video Resolution | • Main Profile: 1080p (1920 x 1080) at up to 30 fps • Secondary Profile: 720p (1280 x 720) at up to 15 fps |
|
| Audio Support | •MPEG-2 AAC LC | |
| Network | ||
| Connectivity | • 802.11n/g/b wireless with WPA/WPA2 encryption • Operates on 2.4 GHz band • microSD card slot2 • Single-band 2T2R mode supports a maximum data rate of 150 Mbps (PHY rate) using 20 MHz bandwidth • Bluetooth Low Energy (BLE) 4.0 |
|
| Network Protocols | • IPv6, IPv4, ARP, TCP/IP, UDP, ICMP • DHCP Client • HTTPS • Bonjour |
|
| System Integration | ||
| Event Management | • Motion detection • Sound detection • Cloud recording • Manually taken snapshots and video clips are saved to mobile device or SD card • Push Notifications |
|
| Mobile support • | • mydlinkTM app for iPhone®, iPad®, and AndroidTM phone and tablet | |
| Physical | ||
| Environment | • For indoor and outdoor use • IP65 weatherproof rating |
|
| Weight • | Camera: 10.2 oz • Wall mount: 1.1oz |
|
| Power Adaptor | • Input: 100 to 240 V AC, 50/60 Hz • Output: 5 V DC 2.0A (Micro-USB) • Cable length 23 ft: Camera: 9.84 ft, Power adapter: 13.12 ft |
|
| Power Consumption | Maximum 6 W ± 5% | |
| Temperature | • Operating: -4 to 113 °F • Storage: -13 to 158 ˚F |
|
| Humidity | • Operating: 20% to 80% non-condensing • Storage: 20% to 80% non-condensing |
|
| Certifications | • CE • CE LVD • FCC • RCM • ICES |
|
| Dimensions (H x W x D) | 3.46 x 3.46 x 2.74 in | |
Documentation:
Download the D-Link DCS-8600LH Datasheet (PDF).
