D-Link DGE-560T
Gigabit Desktop PCI Adapter

D-Link Products

DGE-560T

Gigabit PCI-Express Network Adapter

#DGE-560T
List Price: ~~$22.99~~
Our Price: $21.84

Overview
Specifications

Overview:

Add high-speed Gigabit Ethernet connectivity to any system with a PCI expansion slot.

One 1000 Mbps Gigabit port
Auto-negotiates port speed to 10 Mbps, 100 Mbps, or 1000 Mbps
Plug and play installation
Supports Jumbo Frames of up to 7 KB
ACPI 2.0 WOL Power Management
Supports 802.1Q VLAN tagging

Remote Management

The DGE-530T includes additional advanced features such as Advanced Power Management and Wake-on-LAN support. It also supports remote network boot using both PXE and RPL, allowing network administrators to boot the PC from anywhere on the network.

Versatility

The DGE-530T supports all major operating systems, guaranteeing compatibility with existing workstation and desktop environments. Its half-height form factor allows it to be used in low-profile cases for compact PCs. The card also has a diagnostic utility tool, simplifying troubleshooting.

Specifications:

D-Link DGE-530T Specifications
Certifications	CE
Humidity	Operating: 10% to 90% non-condensing Storage: 5% to 95% non-condensing
Temperature	Operating: 0 to 40 °C (32 to 104 °F) Storage: -40 to 70 °C (-40 to 158 °F)
Dimensions	120 x 120 x 18 mm (4.7 x 4.7 x 0.7 inches)
Supported Functions	7 KB Jumbo Frames, IEEE 802.1p Priority Queues, IEEE 802.1Q VLAN Tagging, Wake on LAN, Remote Boot (PXE), Diagnostics utility
Power Consumption	3.42 W maximum
Data Transfer Rate	Gigabit Ethernet: Up to 2000 Mbps full duplex, Fast Ethernet: 100 Mbps half duplex, 200 Mbps full duplex, Ethernet: 10 Mbps half duplex, 20 Mbps full duplex
Diagnostic LEDs	10/100/1000 Link, 10/100/1000 Activity
Interface	PCI half-height card suitable for low-profile cases
OS Support	Microsoft Windows XP/Vista/7/8/8.1/10, Microsoft Windows Server 2000/2003/2008/2012, Linux for Kernel 2.4.x/2.6.x/3.16, Mac OS X 10.4/10.5/10.6, Free BSD 7.x/8.x, NDIS 2 for DOS, Novell client for DOS, Novell client for server 5.x/6.x
Standards	IEEE 802.3, 802.3u, 802.3ab, PCI local bus 2.2, 2.3, ANSI/IEEE 802.3, NWay auto-negotiation, Universal Bus Support 3.3 V / 5 V, IEEE 802.3x Flow Control
Topology	Star
Weight	50 grams (1.76 ounces)

Pricing Notes:

Pricing and product availability subject to change without notice.
