D-Link DCS-4602EV-VB1
Vigilance 2 megapixel H.265 Outdoor Dome Camera

Sorry, this product is no longer available, please contact us for a replacement.

Overview:

The D-Link DCS-4602EV-VB1 Vigilance 2 Megapixel H.265 Outdoor Dome Camera is a highdefinition professional surveillance solution suitable for small, medium, and large enterprises. The camera uses a high-sensitivity 1/2.7” megapixel progressive scan CMOS sensor with onboard WDR image enhancement to deliver truly superior quality video in all conditions. The all-in-one rugged design makes this camera extremely reliable and ideal for deployment in surveillance applications without the need for additional accessories.

High-Quality Streaming & Recording

To maximize bandwidth efficiency and improve image quality, the DCS-4602EV-VB1 provides real-time video compression using the H.265, H.264, and MJPEG codecs, and supports three separate profiles for simultaneous video streaming and recording. Video resolutions of up to 1920 x 1080 provide clear details, and noise reduction and support for simultaneous video streams improves quality in case forensic work is required for evidence. Additional support for motion detection, event management features, and ePTZ allow for implementation in a wide variety of surveillance applications such as monitoring public areas to detect incidents and to coordinate responses, enforcing access control to restricted areas, deterring criminal activity, or monitoring inventory.

Versatile Monitoring in All Environments

The DCS-4602EV-VB1’s features WDR image enhancement to deliver improved image quality in conditions with uneven or difficult lighting, so you can identify subjects that are backlit or in brightly-lit areas. In low-light situations, the IR-cut filter automatically slides out of the way to use all available light. The DCS-4602EV-VB1 also has built-in IR LED illuminators with a 20-meter range, allowing the camera to keep watch even in complete darkness. IP66 certification ensures the camera is completely protected from dust and water in any environment and IK10 certified vandal-proof housing makes sure it keeps recording even when intruders attempt to sabotage the camera. These features work together to give you a reliable surveillance camera capable of monitoring indoors or outdoors 24/7.

Features:

Exceptional Video Quality

1/2.7” megapixel progressive CMOS sensor
Full HD resolution of 1920 x 1080
Wide Dynamic Range (WDR) image enhancement
H.265, H.264, MJPEG codec support for streaming and recording
Motion detection
Privacy mask

Outdoor Placement

Built-in IR LED illuminator with a 20-meter range for use in dark areas
Range of mounting options for flexible placement
Rugged IP66 weatherproof housing
IK10 vandal-proof housing to protect unit when mounted outdoors

Flexibility

10/100 Fast Ethernet port
Power over Ethernet (PoE) ensures easy and flexible integration into your network
microSD card slot for onboard storage¹

Specifications:

Camera

Camera Hardware Profile

1/2.7” 2 Megapixel Progressive CMOS Sensor
60 ft IR Illumination Distance
Minimum illumination
- .1 Lux Color mode
- 0.05 Lux Black and White mode
- 0 Lux Black and White mode with IR LED on
Bulit-in Infrared-Cut Removable (ICR) Filter module for night viewing
10x digital zoom
Minimum object distance .2M
Focal length:2.8mm
Aperture: F2.0
Angle of view:
- 120° horizontal
- 66° vertical
- 140° diagonal
2-Axis gimbal adjustment angles (non-motorized)
- Vertical: 30~60°
- Horizontal: 120~120°

Camera Housing

IP66 compliant weatherproof housing
IK10 compliant vandal-proof housing

Image Features

Configurable image size, quality, frame rate, and bit rate
Configurable motion detection windows
Configurable privacy mask zones
Configurable exposure time, brightness, saturation, contrast, contrast, sharpness, digital WDR and 3D filter
Auto White Balance (AWB)
Auto Gain Control (AGC)
Wide Dynamic Range (WDR)
Time stamp and text overlays

Video Compression

Simultaneous H.265/H.264/MJPEG format compression
H.265/H.264/MJPEG multicast streaming
JPEG for still images

Video Resolution

16:9 - 1920 x 1080, 1280 x 720, 800 x 448, 640 x 360 up to 30 fps
4:3 - 1600 x 1200, 1440 x 1080, 1280 x 960, 900 x 720, 800 x 600, 640 x 480 up to 30 fps

External Device Interface

10/100 BASE-TX Ethernet port with PoE
Supports 802.3af PoE Class 3

Network

Security

Administrator and user group protection
Password authentication
HTTP and RTSP digest encryption

System Management

Event Management

Motion detection
Tamper detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Supports multiple SMTP and FTP servers
Multiple event notifcations
Multiple recording methods for easy backup

Remote Management

Take snapshots/video clips and save to local hard drive
Configuration interface accessible via web browser

System Requirements for Web Interface

Operating System: Microsoft Windows 10/8/7
Browser: Internet Explorer, Firefox, Chrome

D-ViewCam™ System Requirements

Operating System:
- 32-bit Microsoft Windows 8/7/ (SP1)
- 64-bit Microsoft Windows 10/8/7/ (SP1)/ Server 2012 / Server 2008 R2
Web Browser: Internet Explorer 7 or higher
Protocol: Standard TCP/IP

D-ViewCam™ Software Functions

Remote management/control of up to 32 cameras
Supports all management functions provided in web interface
Viewing of up to 32 cameras on one screen
Scheduled motion triggered, or manual recording options

General

Weight

.80 lbs (365 grams) ±5%

Power

Input: 100 to 240 V AC, 50/60 Hz
Output: 12V DC 1.25 A

Power Consumption

6.6 Watts ±5%(PoE)

Temperature

Operating: -22° to 124° F (-30° to 50° C)
Storage: -4 to 158° F (-20° to 70° C)

Humidity

Operating: 20% to 80% non-condensing
Storage: 5% to 95% non-condensing

Certifications

CE
CE LVD
FCC
RCM

Warranty

5-Year Limited Warranty

Documentation:

Download the D-Link DCS-4602EV-VB1 Datasheet (PDF).
