D-Link DCS-8300LH
Full HD Wi-Fi Camera
Sorry, this product is no longer available, please contact us for a replacement.
Overview:
Your Home, Only Smarter
The DCS-8300LH Full HD Wi-Fi Camera boasts a wide-angle lens that easily captures your entire room, wall-to-wall, in high-quality 1080p. You will know what is happening day or night with built in night vision, motion and sound detection sending notifications to the mydlink app. The rotatable head makes discrete installations easy even on ceilings.
Peace of Mind with 24/7 Complete Coverage
The DCS-8300LH uses a 137° wide-angle lens and a 1080p HD sensor to give you a clear view of an entire room with a single camera. The DCS-8300LH enables round-the-clock monitoring with built-in infrared LEDs allowing up to 16 feet of night time viewing. The special fold-out design makes ceiling, wall, and counter-top installations a breeze while wireless 802.11n keeps cabling to a minimum.
Get Notifications Wherever You Are
The DCS-8300LH helps you keep watch over the things that are important to you with built-in motion detection that can send push notifications to your mobile phone and automatically record snapshots and video clips to a microSD card or to your cloud account. Sound detection will notify you of loud noises, such as a baby crying or glass breaking, making it ideal for use as a baby monitor or office camera.
Do it All with the mydlink® App
Now enhanced with the new mydlink® app, the DCS-8300LH makes it easier and more convenient for you to look after your family at home or check in on your office — from anywhere with Internet access. Simply install the app on your mobile device and you’ll be able to set up, view, and manage your camera using your tablet or mobile phone. With the mydlink® app, you will always feel protected.
Anytime, Anywhere Access with mydlink® Cloud Recording
Enhanced with mydlink® cloud recording support, the DCS-8300LH makes it easy and convenient for you to look after your family and check up on your home or office. With a mydlink® cloud recording subscription, you can have peace of mind with your video recordings sent automatically to a cloud server. Play back recordings from the cloud or download video clips to your mobile device from anywhere, anytime through the Internet. Access real-time live views of your cameras using the mydlink® mobile app and set automated schedules via your mobile device, no matter where you are.
Features
- High quality Full HD sensor provides detailed snapshots and crisp video
- Built-in IR LEDs to capture video in low-light environments, or even complete darkness up to16 ft (5 m)
- Motion and sound level detection
- Push notification for events and save video clips to microSD card or cloud storage
- Uses Wireless N so you can install the camera anywhere with ease
- Backwards compatible with 802.11b/g
- View and manage your camera using the mydlink® app
- Pinch to zoom allows for closer looks on what is happening in the room
- AES128-encrypted video and audio streaming
Technical Specifications:
D-Link DCS-8300LH Technical Specifications | |
---|---|
Camera | |
Camera | • 1/2.7” progressive CMOS sensor • 16 ft (5 m) IR illumination distance • Minimum illumination: B/W (Night Mode), IR LEDs on: 0 lux • Built-in Infrared-Cut Removable (ICR) Filter module • Fixed length 2.7 mm • Aperture F2.4 • Angle of view (16:9): Horizontal: 137°, Vertical: 71°, Diagonal: 167° • Built-in microphone • Built-in speaker |
Image Features | • Configurable image size • Configurable sound level detection • Configurable motion detection windows |
Video Compression | • Simultaneous H.264/MJPEG format compression • JPEG for still images |
Video Resolution | • Main Profile: 1080p (1920 x 1080) at up to 30 fps • Second Profile: 720p (1280 x 720) at up to 15 fps |
Audio Support | • MPEG-2 AAC LC |
Network | |
Connectivity | • 802.11b/g/n wireless with WPA/WPA2 encryption • Operates on 2.4 GHz band • microSD card slot • Single-band 1T1R mode supports a maximum data rate of 72.2 Mbps (PHY rate) using 20 MHz bandwidth • Bluetooth 2.1/3.0/4.0 |
Network Protocols | • IPv4, IPv6, ARP, TCP, UDP, ICMP • DHCP Client • DNS Client • RTSP/SRTP • HTTPS • Bonjour |
System Integration | |
Event Management | • Motion detection • Sound detection • Cloud recording • Manually taken snapshots and video clips saved to mobile device • Push Notification |
Mobile Support | • mydlink® app for iPhone, iPad, Android phone and tablet |
Physical | |
Environment | • For indoor use only |
Weight | • 105 g (3.7 oz) ± 5% |
Power Adaptor | • Input: 100 to 240 V AC, 50/60 Hz • Output: 5 V DC 1.2A (Micro-USB) |
Power Consumption | • Maximum 5 W ± 5% |
Temperature | • Operating: 0 to 40 °C (32 to 104 °F) • Storage: -20 to 70˚ C (-4 to 158 ˚F) |
Humidity | Operating: 20% to 80% non-condensing • Storage: 5% to 95% non-condensing |
Certifications | • CE • CE LVD • RCM • FCC Class B • ICES |
Dimensions (L x W x H) | • 2.6 x 2.6 x 4.31 in (66 x 66 x 109.6 mm) |
Documentation:
Download the D-Link DCS-8300LH Datasheet (PDF).
